Watch Ibeacon Waterproof Cheap Rechargeable Ble Wrist Band Watch Beacon Bluetooth Low Energy IP67 Waterproof Ibeacon

Watch Ibeacon Waterproof Cheap Rechargeable Ble Wrist Band Watch Beacon Bluetooth Low Energy IP67 Waterproof Ibeacon

$10.00

Availability:In Stock
Product Code: map62793

Add to Wish List

Compare

Description
Reviews (0)

Cheap rechargeable ble wrist band watch beacon bluetooth low energy IP67 waterproof ibeacon

Product Description

W2 Wristband Beacon
1. wearable bracelet shape with silver gray
2. IP67 Waterproof
3. 3-axis accelerometer sensor with motion trigger
4. Touch button with SOS Trigger function
5. Rechargeable Li battery, USB direct charging
6. Compatible with iBeacon™,Eddystone™ (UID, URL, TLM) and sensor in turn
7. All parameters can be modified via MokobeaconX Pro APP

Features

Advertising Beacon Device
Ultra-low power consumption chipset NRF52 Serise
Supporting BLE5.0
Ultra-low power consumption chipeset NRF52 serial
Support button trigger and motion trigger
Firmware updated via DFU
Customizable to increase NFC to wake up bluetooth (MOQ:1000pcs)
Logo and wristband color customizable (MOQ 200units)
Provided with your own configuration (MOQ 100 units)

Electronic parameters

Item	Value	Remarks
Case Color	silver gray	Other colors can be customized
Main Material	TPU+PC	-
Battery Model	Lithium polymer battery	Rechargeable lithium battery, 80mAH 3.7V Simple USB direct charge
Battery Lifetime	About 2 months	At default settings and without selfdischarge factor With battery notifications
Operation Voltage	3.3V	DC
Waterproof Level	IP67	-
Static Current	14.7 uA	Device is power off
Average Current	50 uA	At default settings
Transmission Range	>55m	4dBm TX power，in the open space
Antenna	50ohm	On board/PCB Antenna
Size	Body size: 40.89x20.18x12mm Wearable range: 13cm~21cm	Refer to mechanical draws for details
Net Weight	24.8g	With battery
Operating Temperature	-20 ~ +60ºC	-
Storage Temperature	20 ~ +30ºC	-
NFC	NFC tag	Only NFC tag is supported(The signalling type is NFC-A). You can wake up the Beacon from NFC(The Beacon will be turned on after touching NFC reader).

Mechanical draws

Configurable SLOTs and parameters
* Up to 6 configurable SLOTs;
* Each SLOT can be set to iBeacon，UID，URL，TLM，Device Info and 3-axis Sensor data;
* Device Name, Password, Connection Mode, Advertising Interval, Tx Power and 3-axis Sensor Parameters all are configurable;
* Special Configuration APP ( BeaconX Pro), available for iOS and Android.

Flexible sensor function
* 3-axis accelerometer has dynamically user-selectable full scales of ±2g/±4g/±8g/±16g and the paremeter is configurable ；
* 3-axis accelerometer is capable of measuring accelerations with output data rates from 1 Hz to 100 Hz and the paremeter is
configurable；
* User can get the raw data of the 3-axis sensor sampling data from the device in real time；

Trigger function
* Support button trigger and motion trigger;
* Control the device to start advertising all the time, stop advertising, or advertise for a while.

How to use it ?

If you'd like to set up your own Physical Web beacon, you can follow these steps below
1. Download the “Moko BeaconX Pro” from App Store or Google Play
2. Turn ON/OFF BeaconX Pro. Then scan and connect to BeaconX Pro
3. Configure BeaconX Pro Parameters: Click the corresponding parameters to change the data, then Click top right corner's 'Save' to save the changes

Certifications

Shipping

Company Introduction

Our Services

1. OEM / ODM Manufacturing welcome: Product, Package, etc.
2. Sample order acceptable, small MOQ.
3. We will reply you for your inquiry in 24 hours.
4. After sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.

FAQ

Q1: Do the Beacons work with IOS and Android phones?
A1: Yes, We will send the user manual to you to set up the beacon ,you can test the Beacon with IOS and Android phones.

Q2: Do you provide the technical support to the developers?
A2: SURE. The following technical data and documents will be provided.
1.Android&IOS SDK 2. Configuration APP 3. SDK description

Q3: Is the Beacons Certified ?
A3: Yes, all of our Beacons are with FCC/CE/RoHS Certificates, we can provide to customers anytime if needed.

Q4: If the beacon can be managed remotely ?
A4: Yes, you can use our app to connect the beacon within the beacon range area to change the paramters.

Q5: If there have monthly charge after we purchased the beacon from you ?
A5: NO, we won't have monthly charge for our clients.

Q6: Could brand the product with our company LOGO?
A6: Yes, pls send an AI file with your logo to us, then our engineer will access for you.

Q7: What's the warranty of the product?
A7: we supply 1 year warranty from the shipping date, any damage caused during the production would be replace by a new one.

Q8: Could we have an customized beacon ?
A8: Yes, We offer the OEM/ODM service.

For more questions, Welcome to contact us.
